This is upstream open hardware, not a Resin-authored design or customer project.
The source is a KiCad 4-era project and must be migrated before saving in a current editor.
No Resin import-fidelity, DRC-clearance, fabrication, calibration, or current component-availability claim is made.
CERN OHL v1.2 attribution and source-sharing obligations remain attached to redistributed source material.
All 27 conversion checks met their stated condition, including footprint reference/value preservation and KiCad 9.0.7 acceptance; bounded checks do not establish full semantic or manufacturing fidelity.
The bounded Resin DRC record retains per-family completion, timeout, timing, and raw pre-dedup finding data; it is not a complete or deduplicated DRC result.
A production-scale open industrial controller with protected field interfaces, isolated digital inputs, analog I/O, memory, power, and a dense routed PCB.
This is upstream open hardware, not a Resin-authored design or customer project.
The source is a KiCad 5-era project and saving it in a current editor may produce a broad format migration.
No certification, EMC, safety, environmental, manufacturing-yield, or current component-availability claim is made.
The communications interfaces are protected, but galvanic isolation is demonstrated primarily by the digital inputs.
Twenty-five of 27 conversion checks met their stated condition; footprint values are not surfaced and KiCad 9.0.7 rejects the converter's target format version.
Nine of fourteen bounded Resin DRC families completed with 447 raw pre-dedup findings; five timed out and the full KiCad CLI DRC path errored.
Inspect a dense routed board from KiCad's official GPL-3.0-or-later demo set through Resin's native parser and renderer.
189 footprints7,932 routed segments808 vias
Useful for: Byte-exact KiCad source ingestion, structural counting, native front/back SVG rendering, a completed KiCad CLI DRC report, and a time-bounded Resin-native family run on a dense routed board.
This is an official KiCad demo distributed by the KiCad project; it is not a Resin-authored design or customer project.
KiCad CLI completed in 17.38 seconds with 243 reported violations: 25 errors and 218 warnings. This is not a clean-board result.
The bounded Resin-native run completed 5 of 14 families and timed out 9 families at 30 seconds each. Its 458 raw pre-dedup findings cannot support a complete native DRC conclusion.
No .kicad_pro or .kicad_dru accompanies the board, so project-aware rules and net classes were unavailable.
No fabrication, assembly, electrical performance, compliance, or built-hardware acceptance is claimed.
Inspect the source, result, and report as separate things.
A render can show structure, a conversion report can show measured differences, and an output file can be opened by a receiver. None of those alone proves the entire workflow.
Check identity
Use the published revision, hashes, license, and provenance before comparing files.
Open the actual files
Use an appropriate independent tool rather than judging compatibility from a screenshot.
Keep the stated boundary
Do not describe third-party boards as designed in Resin or uninspected outputs as manufacturing-approved.
Next decision
Continue with the workflow that matches the collection.
Use the examples as inputs to a representative product test.
