Examples

See what Resin looks like—and test it with real project files.

Start with product captures to understand the editor. Then inspect complex routed boards or download focused import and manufacturing fixtures for your own evaluation.

Ways to evaluate: 3 focused collections
Product tour: 6 first-party captures
Access: No account required

Choose an example Try Resin

Choose your evidence

Start with the question you need to answer.

Each collection is useful for a different buying decision. The labels below separate what you can inspect from what the example does not establish.

Product tourBest first look

See the Resin editor on a real schematic

Follow one captured power project through the schematic, BOM, symbol library, output setup, changes, and history views.

6 first-party product viewsCapture-only evidence

Not shown: a routed PCB, downloadable source project, or generated manufacturing package.

See Resin in action

Front copper, mask, and silkscreen render of the six-layer ScopeFun v2 mixed-signal instrument board

Routed-board referencesFor judging scale

Inspect boards with real routing complexity

Explore three pinned open-hardware boards with measured structure, native renders, downloadable files, and disclosed check results.

3 complex routed boardsThird-party source designs

Not shown: boards authored in Resin, clean DRC results, or fabricated-hardware validation.

Inspect routed boards

Native PCB render of the imported CAN bus fixture with five footprints and no routed copper

Import and output fixturesFor hands-on testing

Open the actual source and result files

Download bounded Altium import, board-geometry, and manufacturing-output packages with reports and known limitations.

Source, result, and report filesNarrow test fixtures

Not shown: universal import fidelity, production approval, or manufacturer acceptance.

Download test fixtures

Match the example to the decision

What each example can answer

Use the product tour for interface questions, routed boards for complexity, and downloadable fixtures when you need to inspect files yourself.

What does working in Resin look like?

The power-architecture tour shows six connected product views from one captured schematic project.

Can Resin represent boards at our level of complexity?

The routed-board collection provides measured structure, renders, and disclosed check behavior for three complex open-hardware designs.

What happens to files at import and export?

The compatibility collection provides source files, generated results, reports, and manufacturing outputs you can open independently.

Try it with your work

Move from browsing examples to testing Resin.

Create an account to explore the editor, or use the evaluation guide to choose a representative project and define what your team needs to verify.

Ready to open Resin?

Start a project in the browser and compare the experience with the evidence you reviewed here.

Create an account Plan a team evaluation
