Check the exact format path
Confirm the source tool, version, file type, and supported direction rather than treating a format family as universally compatible.
Import and export
Move existing PCB projects into Resin with a testable path.
Start with a supported source, inspect the imported schematic and PCB objects, and verify the outputs your downstream tools require before moving production work.
No credit card required.
Core capabilities
What you can do in Resin.
Pilot one representative project
Use a copy that contains the hierarchy, libraries, board objects, rules, and special cases that matter to your team.
Inspect imported engineering objects
Compare sheets, connectivity, parts, board geometry, layers, routing, and rules against the source in the tools that understand them.
Verify downstream outputs
Open exported files in their receiving tools and keep the original source available until the migration is accepted.
Resin EDA
Start designing in Resin.
Open the schematic and PCB workspace in your browser. No credit card required.
Questions about team access, security review, or purchasing? Write to hello@resineda.com.
